The Concrete Block Making Machine is a brick-making equipment that specializes in the production of concrete products. Different models of block forming machines are selected according to the output. According to the investment scale, you can choose simple type, optimized type, selected type, semi-automatic configuration, fully automatic configuration, etc. Block forming machine-made brick production line. The feeding system sends concrete raw materials into the mixing system through a conveyor belt. The hopper in the mixing system will mix cement, sand and other raw materials, and add an appropriate amount of water to stir the raw materials evenly. The forming system places the uniformly mixed concrete raw materials into the forming machine, which has different molds to produce concrete blocks of different shapes and sizes. The concrete block forming machine is simple to operate, has high production efficiency, and the quality of the concrete blocks produced is stable.
Product Features
German Design - Higher Efficiency & Lower Failure Rate;
Made in China - Lower Cost & Better service.
ZN1000C block machine adopts German technology, the leading technology for block machine in the world. German technology is known for its rigor and simplicity, paying more attention to the overall performance, efficiency, and machine quality.
ZN1000C block machines are produced in China, strictly accordingly to German technology and craftsmanship. Compared with other brand of block machines, ZN1000C machines have more stable performance, higher production efficiency and lower failure rate. In terms of performance, efficiency, energy-saving, environmental protection, etc., it is far ahead of other block machines in the market.
Technical Parameters
| Forming Area | 1100×820mm |
| Height of Finished | 50-300mm |
| Cycle Time | 15-25S (as per mould) |
| Vibration Force | 80KN |
| Pallet Size | 1200x870x（12-45）mm |
| Production per Mold | 390x190x190mm（10pcs/mold） |
| Bottom Vibration | 2x7.5KW（SIEMENS） |
| Top Vibration | 2x0.55KW |
| Electrical Control | SIEMENS |
| Power | 42.25KW |
| Total Weight |
8T（Without Facemix） 11T（With Facemix） |
| Dimension | 6145x2650x3040mm |
